HCAS-2620ES-HD
Short reach professional articulating shafted hedge trimmer provides ease of use with precise trimming.
The ECHO HCAS-2620ES-HD is a professional grade, short reach articulating hedge trimmer weighing just 6.2kg with ergonomic and balanced construction. Featuring a heavy duty air filter to massively reduce the need for maintenance, ECHO's ES-Start system for effortless starting and easy one-handed blade angle adjustment.
EAN code: 4934110704502
- Rated power (kW)
- 1
- Dry weight (kg)
- 6.3
- Cutter pitch (mm)
- 35
Product
Technologies
ES-Start
Spring-assisted system makes starting significantly easier.
Tip Guard
Heavy Duty Air Filter
Adjustable Cutter Clearance
Adjustment Free
Adjustment-free cutter clearance.
Product
Specifications
- Rated power (ps)
- 1.4
- Rated power (kW)
- 1
- Engine type
- 2 stroke
- Power source type
- Petrol
- Dry weight (kg)
- 6.3
- Fuel mix ratio
- 2
- Heavy Duty air Filter
- true
- Air filter type
- Pleated paper + foam
- Choke
- true
- Primer pump
- true
- Starting mode
- ES Start
- Cutter pitch (mm)
- 35
- Adjustable cutter clearance
- true
- Stroke rate (cuts/min)
- 5000
- Cutting length (cm)
- 53.6
- Cutting pitch (mm)
- 35
- Tooth type
- Triple sharpenned
- Blade material
- Laser cut steel
- Blade movement mode
- Dual opposing
- Blade type
- Double
- Output (kW)
- 1
- Output (ps)
- 1.4
- Adjustment-free
- true
- Fuel consumption at maximum engine power (L/h)
- 0.61
- Displacement (cm³)
- 25.4
- No-load speed (r/min)
- 11500
- Fuel tank capacity (mL)
- 600
- Carburetor type
- Diaphragm
- Ignition type
- CDI
- Clutch type
- Centrifugal
- Sound pressure level (dB(A))
- 96.5
- Sound power level (dB(A))
- 110.3
- Emmission certification
- true
- CO² (g/kW・h)
- 998
- Power unit manufacturer
- YAMABIKO
- Vibration Front handle / Rear handle (m/s²)
- 8.1 / 9.4
- Hedge trimmer handle type
- Fixed
- Hedge trimmer front handle material
- Synthetic
- Front handle soft grip
- true
- Rear handle soft grip
- true
- ES-Start
- true
- Tip guard
- true
- Speed selection
- No
- Toolless adjustable air filter cover
- true
